Meent mounts the Integrated Modular Wall Diagnostic Station in the central triage bay, enabling nursing staff to capture the patient’s blood pressure, heart rate, SpO2, temperature, and weight in a single station. The station integrates an oscillometric NIBP module with a paediatric and adult cuff, an infrared tympanic thermometer (35.5-42.0 C, accuracy +/-0.2 C), and a pulse oximeter with a reusable finger clip. A built-in touch-screen tablet displays all parameters on a combined dashboard and flags values outside age-based normal ranges with a yellow alert.

The station’s integrated ophthalmoscope and otoscope heads – the same as those in the ENT solution – give the general practitioner immediate access to fundoscopy and tympanic membrane examination. A pull-out drawer contains disposable specula, alcohol wipes, and a Snellen near-acuity chart. Readings are transmitted via Bluetooth to the clinic’s tablet-based electronic health record, eliminating manual transcription.

Technical Note: The NIBP module requires a daily pressure relief test: inflate the system to 250 mmHg with the cuff wrapped around a rigid cylinder and confirm that the valve releases pressure within 10 seconds. The tympanic thermometer’s probe cover sensor must detect the presence of a clean cover; a faulty sensor allows a measurement without a cover, contaminating the lens and requiring disinfection.

For patients complaining of hearing difficulty or as part of an annual health check for the elderly, Meent supplies the Portable Audiometer. This hand-held device delivers air-conduction pure tones at 0.5, 1, 2, and 4 kHz at fixed intensities of 25, 40, and 60 dB HL. The primary care nurse performs the screening in a quiet side-room (ambient noise <50 dBA). The patient raises a hand when they hear the tone; results are recorded on a simple “Pass/Refer” card. Any patient failing to hear 25 dB HL at any frequency in either ear is referred to the audiology center for diagnostic testing.

The Portable Audiometer is battery-operated (2x AA, 10-hour runtime) and calibrated with a daily listening check using a staff member with known normal hearing. An inbuilt tone counter prevents overtesting; after 1,000 tone presentations, a service screen appears, reminding the clinic to send the device for annual calibration.

Technical Note: The screening room’s ambient noise level is assessed monthly using a smartphone sound-level app validated against a Type 2 meter; if the level exceeds 50 dBA, the screening must be moved or postponed until quiet conditions are restored. Foam earphone cushions are replaced monthly or when visibly soiled.

Meent installs a Dental Chair identical to that in Solution One, configured for general dentistry and oral examination. The chair is positioned in a treatment bay with a side cabinet for instruments. The Air Compressor (oil-free, 50 L/min) is placed in a sound-dampened cabinet in the adjacent sluice room, supplying 2.8 bar dry air to the dental unit via a quick-connect hose. The compressor’s tank has an automatic drain and a pressure gauge visible through a tempered glass window.

The general practitioner can perform basic dental procedures – extraction of mobile teeth under local anaesthetic, drainage of a periapical abscess, and temporary restoration using glass ionomer cement. The dental unit’s 3-way syringe provides air, water, and a mist for rinsing. Instrument cassettes with a basic dental examination set (mirror, probe, tweezers) are stored in sealed pouches until use.

Technical Note: The compressor must be placed outside the clinical zone because its noise level of 55 dBA at 1 m exceeds the WHO recommendation for quiet areas. The tank’s safety valve is tested monthly by pulling the ring when the tank is at full pressure; a valve that does not release freely must be replaced immediately.

Meent provides the Dental Autoclave (18-litre Class B) for the sterilization of all reusable instruments – dental examination kits, suture removal sets, and minor surgery instruments (scalpel handles, forceps). The autoclave is located in the clean utility room, and its operation is identical to that described in Solution One, with a daily Bowie-Dick test and biological indicator monitoring. Due to the lower procedural volume in a primary care setting, the unit is programmed for an economic “half-load” cycle (121 C for 20 minutes) for non-critical items, while hollow instruments continue to undergo a full 134 C cycle.

The autoclave’s water reservoir uses distilled water from a wall-mounted still. A logbook next to the autoclave records the date, cycle type, temperature achieved, and operator initials. A new biological indicator is placed in the first cycle of each week; results are read after 48 hours of incubation and scanned into the electronic record.

Technical Note: The autoclave’s chamber filter must be cleaned monthly under running water to remove lint and paper residue from autoclave bags. A clogged filter increases cycle time by up to 8 minutes and can result in wet packs, which are considered non-sterile and must be reprocessed.

Meent integrates a basic clinic management application into the wall diagnostic station’s tablet, displaying a unified calendar for the shared dental chair and autoclave. The triage nurse schedules dental extractions in 30-minute blocks, general medical consultations in 15-minute blocks, and dedicated hearing screening slots during the afternoon geriatric clinic. A colour-coded floor-plan view shows real-time equipment occupancy.

The application also tracks consumables: the autoclave’s sterilization pouches, dental local anaesthetic cartridges, and ear specula. When stock falls below a 2-week buffer, a purchase order is automatically generated and emailed to the district supply office. Monthly reports provide the clinic manager with utilization statistics – number of dental procedures, hearing screens performed, NIBP readings recorded – to support resource planning and grant applications.

Technical Note: The application runs on a local area network with a fallback cellular modem for areas with unreliable broadband. All data is synchronised to a central health information exchange when connectivity permits, using FHIR R4 standards for interoperability.
